Specification:
1.Model No.: KYD-EP2007
2.Basket Size: L410 xW280 xH160mm±3mm
3.Hanging basket material: the frame is 201# stainless steel, the handle is 5mm diameter round steel bar, the panel is anti-static plastic material, and the pull stud is carbon steel galvanized
4.Hanging Basket inner angle: 90 degrees
5.Production method: stainless steel edging
6.Number of the PCB plate can be stored in each hanging basket: 38pcs
7.Hanging Basket guide groove: Vertically insert
8.Groove depth: 3mm
9.Width: 3mm
10.Slot length: 220mm
11.Groove height: 140mm
12.Grid spacing: 10mm
13.Surface resistance: 104Ω---109Ω
14.Hanging Basket bearing weight: 5KG
15.Packing: 8pcs/CTN, 80 x 46 x 37cm/CTN, G.W. about 12kg/CTN
Application: for LCD screen, mobile phone screen, PCB storage. It's mainly used together with SMT utility carts.
